Charlotte Pipe Abs 00331 0600HA Abs Dwv 1-1/2 in Vent Elbow

Product Description

The CHARLOTTE PIPE FOUNDRY CO. ABS 00331 0600HA is a 1-1/2 inch ABS DWV vent elbow designed to make a 90-degree turn in a residential or light commercial venting run. Constructed from black ABS material, this hub x hub fitting connects into standard drain, waste, and vent piping systems without the need for pressure-rated components. It is intended strictly for non-pressure drain, waste, and vent applications. Licensed plumbers and pipefitters install this fitting during rough-in work when the vent stack or branch vent line requires a direction change. The low chemical resistance rating is appropriate for typical sanitary waste and vent service conditions.

This elbow is used in ABS DWV piping systems where a 90-degree direction change is needed within a venting run. Common install scenarios include branch vent lines, vent stack offsets, and air admittance applications in residential new construction and remodel work. The hub x hub end configuration accepts standard 1-1/2 inch ABS pipe on both ends, solvent-cemented per manufacturer and code requirements. It is not rated for pressure service, drainage of corrosive chemicals, or outdoor UV-exposed installations without protective coating.

Key Features

• 90-degree turn geometry for vent line direction changes
• Hub x hub end connections accept standard 1-1/2 inch ABS pipe
• Black ABS material suited for non-pressure DWV service
• Non-pressure rated — correct for drain, waste, and vent use only
• Packaged 20 units per package for job-lot purchasing

Compatibility

Designed as an OEM-style fitting for standard 1-1/2 inch ABS DWV piping systems used in non-pressure drain, waste, and vent installations.

Installation Notes

Installation is performed by a licensed plumber in accordance with the International Plumbing Code (IPC) or applicable local code. Shut off water supply and ensure the system is depressurized before cutting into an existing line. Both pipe ends and hub sockets must be cleaned, primed if required by local code, and solvent-cemented with ABS-rated cement. Do not use this fitting in pressure piping, hot water supply lines, or applications involving concentrated solvents or chemicals beyond the scope of standard sanitary waste service.
