Chamflex CH075048FM1000 Hvac Chamflex Hose Swivel Mnpt x Fixed Mnpt 3/4 X 48

Product Description

The CHAMFLEX CH075048FM1000 is a 3/4" x 48" stainless steel braided hose assembly for water source heat pumps, fan coils, VAV boxes and chilled beams. These hoses are made in the USA and comply with requirements for the “Buy American Act”. Hoses have a minimum of 400psi working pressure and are rated for temperatures between -40°F to 212°F.

• Stainless Steel Braided Hose Assembly
• Complies with requirements for the “Buy American Act”
• Minimum of 400psi working pressure

Product Highlights

This hose assembly features stainless steel construction, compliance with the Buy American Act, and a minimum working pressure of 400psi.

Product Information

Standard Information

• Brand: CHAMFLEX
• Manufacturer Part Number: CH075048FM1000
• Country of Origin: USA

Technical Specifications

• Brand: Chamflex
• Coil Length: 48"
• Composition: Stainless Steel Braid Covered Thermoplastic Tube, Plated Steel Fittings, Adapters
• Connection Size: 3/4"
• Diameter: .75"
• Inside Diameter: 3/4"
• Length: 48
• Maximum Pressure (PSI): 1600
• Outside Diameter: .969"
• Prop 65: Yes
• UL Listed: Yes
• Country of Origin: USA
• Approvals: Thermoplastic Tube UL-94 VO
• Size [Features]: 3/4"
• Material [Features]: Stainless Steel Braided
• Connection Type [Features]: MNPT x MNPT
• Length (Inches) [Features]: 48"
• Category: Air Conditioning Installation Parts
• Manufacturer: ChamFlex
• MPN: CH075048FM1000
• Subcategory: Heat Pump Braided Hoses
• Size: 3/4"
• Connection Type: MNPT x MNPT
• Material: Stainless Steel Braided
