Cgw Abrasives 38203 Bench Wheels, Blue Alum Oxide, Single Pack, Type 1, 8 X 1, 1 inches Arbor, 60, K

Product Description

The CGW ABRASIVES 38203 bench wheel is a straight vitrified wheel used for off-hand tool sharpening and grinding. It is suitable for HSS over 55 RC, high carbon tool steels, and woodworking applications. Bench and pedestal wheels are for use in maintenance departments, tool and die shops, and metal fabrication shops.

• Includes bushing for 1/2", 5/8", 3/4" and 1" ( for 8" wheels ) arbor holes
• Excellent for materials RC55 and above
• Friable grain and cooler bond

Product Highlights

The CGW ABRASIVES 38203 bench wheel is engineered for free cutting action while pulling heat away from the part and into the matrix of the wheel.

Product Information

Standard Information

• Brand: CGW ABRASIVES
• Manufacturer Part Number: 38203
• Country of Origin: IL

Technical Specifications

• Abrasive Material: Blue Aluminum Oxide (AZ)
• Applications: Off-Hand Tool Sharpening & Grinding
• Arbor Diam [Nom]: 1 in
• Diameter: 8"
• Grit: 60
• Hardness Grade: K
• Speed [Max]: 3,600 rpm
• Thickness [Nom]: 1 in
• Tool Shape: Type 1
• Grade: Medium
• Bond: V32A (Vitrified)
• Specification: AZ60-K8-V32A
• Max Operating Speed: 3,600 RPM
• Material: Aluminium Oxide
• Type: 1 ‰ÛÒ Straight wheel
• Wheel Diameter (Inch): 8
• Wheel Thickness (Inch): 1
• Hole Diameter (Inch): 1
• Wheel Hardness: K
• Bond Type: Vitrified
• Wheel Color: Blue
• Hardness Code: K
• Maximum Rpm: 3600
• Wheel Hardness Rating: Medium
• Grain Structure: 8
• Porous: Non-Porous
• Bushing Included: Yes
• Grain: AZ - Premium Blue Aluminum Oxide
• Dia: 8"
• Thickness: 1"
• Arbor/Shank Size: 1-1/4"
• RPM: 3600
• Abrasive Wheel Diameter: 8"
• Arbor Hole Size: 1-1/4"
• Item: Bench and Pedestal Wheel
• Abrasive Wheel Type: Type 1
• Abrasive Wheel Hardness: K8
• Abrasive Grit: 60
• Max. RPM: 3600
• Application: High Carbon Tool Steels and Woodworking Applications
• Center Hole: 1 in
• Bonding: Vitrified
• Applicable Materials: HSS Over 55 RC and Above, High Carbon Tool Steels and Woodworking
• Wheel Type: Type 1
