Cerro Flow Products 1082 Type M Hard Copper Tubing 1 in

Product Description

The CERRO FLOW PRODUCTS 1082 is a 1-inch nominal, Type M hard-temper copper tube drawn from C12200 copper and supplied in 20-foot straight lengths. Conforming to ASTM B88, this light-wall tube carries an outside diameter of 1.125 inches, an inside diameter of 1.055 inches, and a wall thickness of 0.035 inches. It is lead-free and certified to NSF/ANSI 61, making it suitable for domestic potable water service as well as below-grade facility water lines. Licensed plumbers and HVAC-R technicians install this product in residential, commercial, and industrial piping systems.

Type M hard copper tubing in this nominal size is commonly used for general plumbing and heating supply lines, drainage, waste, and vent (DWV) runs, and other light-pressure applications. The hard temper allows for straight runs between fittings without additional support at close intervals, and the 20-foot length reduces the number of joints required on longer runs. This tubing is appropriate for both interior rough-in work and below-grade installations where approved for that use.

Key Features

• Lead-free C12200 copper drawn to ASTM B88 for consistent wall dimensions and metallurgical integrity
• Type M light-wall profile with 0.035-inch wall thickness reduces material weight while meeting pressure requirements for typical plumbing service
• NSF/ANSI 61 certified and WQA, IAPMO, UL, and CSA listed for broad code acceptance
• Hard temper allows rigid, straight installation runs without the need for continuous support along the tube
• Approved for domestic water and below-grade facility water service
• 20-foot straight length minimizes field cuts and solder joints on long runs

Compatibility

Designed for use with standard 1-inch copper sweat, press, and compression fittings in general plumbing, heating, drainage, waste, vent, and other light-pressure piping applications in residential, commercial, and industrial installations.

Installation Notes

Installation should be performed by a licensed plumber in accordance with the International Plumbing Code (IPC) and applicable local codes. Shut off the water supply and relieve system pressure before cutting or joining tubing. Use a sharp tube cutter to ensure a clean, square cut, and ream the cut end before soldering or pressing to remove any burr that could restrict flow or compromise the joint. Type M hard copper is not recommended for medical gas or high-pressure steam service.

Technical Specifications

• Nominal Size: 1 inch
• Outside Diameter: 1.125 inches
• Inside Diameter: 1.055 inches
• Wall Thickness: 0.035 inches
• Length: 20 feet straight
• Weight: 8.6 pounds
• Type: Type M Light Wall
• Temper: Hard
• Material: C12200 Copper
• Material Specification: ASTM B88
• Process: Drawn
• Lead-Free: Yes
• Color: Red
• Certifications: NSF/ANSI 61, WQA, IAPMO, UL, CSA
• Application: General Plumbing and Heating, Drainage Waste and Vent, Light Pressure Use

Standard Information

• Brand: CERRO FLOW PRODUCTS
• Manufacturer Part Number: 1082
