Century VB2074V1 9.45 Single Speed Evaporative Cooler Motor 115V 1725 RPM 3/4 HP

Product Description

The Century VB2074V1 is a single-speed evaporative cooler motor designed for HVAC applications. This motor operates on one hundred fifteen volts and has a speed of one thousand seven hundred twenty-five revolutions per minute at three-quarters horsepower.

• Features brass current carrying terminal board parts.
• Includes automatic overload protection.
• Designed with a class B insulation rating.

Product Highlights

This motor is suitable for continuous use and has a resilient base for stable mounting. It features moisture resistance and operates efficiently with a maximum ambient temperature of one hundred four degrees Fahrenheit.

Product Information

Standard Information

• Brand: Century
• MPN: VB2074V1

Technical Specifications

• Voltage: 115V
• RPM: 1725
• Frame: 56Z
• Horsepower: 3/4
• Amperage: 10.6
• Phase: 1 (Single)
• Hertz: 60
• Insulation Class: B
• Weight: 18.2 lbs
• Mounting Type: Resilient Base
• Enclosure Type: Open Drip Proof
• Bearings: Ball
