Century UB595 General Purpose Farm Duty Motor 1.0 HP 208-230/460

Product Description

The Century UB595 is a general-purpose farm duty motor designed for various applications. This motor operates on three-phase power with a voltage range of 208 to 230 volts or 460 volts. It offers a power output of one horsepower and features a reversible clockwise rotation. The motor is durable, constructed from rolled steel, and is equipped with sealed ball bearings for protection against contaminants. This design is suitable for use in high-pressure washdown environments, ensuring reliability and longevity.

• Power: 1.0 HP
• Voltage: 208-230/460
• Construction: Rolled Steel with Epoxy coating

Product Highlights

This motor is ideal for agricultural tasks and industrial use where dependability is essential. It features Washguard duty for high-pressure washdown applications and is thermally protected.

Product Information

Standard Information

• Brand: Century
• MPN: UB595

Technical Specifications

• Horsepower: 1.0 HP
• Voltage: 208-230/460
• Frame Size: L56HCZ
• Length: 15.5 inches
• Width: 10.5 inches
• Height: 10 inches
• Weight: 38 pounds
• RPM: 3450
• Shaft Diameter: 0.625 inches
• Shaft Extension: 2.17 inches
• Current: 3.3-3.2/1.6 Amperes
• Operational Phase: Three-phase
