Century UH952 General Purpose Motor 2 HP 3450 RPM

Product Description

The Century UH952 General Purpose Motor is designed for versatile applications and dependable operation. This motor features a polyphase induction type, single or dual voltage with a 2 HP output.

• HP: 2.0
• Frame: P56H
• RPM: 3450

Product Highlights

Century UH952 offers premium efficiency and durable construction. It is UL recognized and CSA certified, ensuring safety and reliability in various environments. The motor includes thermally protected overloads, reversible counterclockwise rotation, and permanently lubricated sealed bearings, extending the motor's lifespan.

Product Information

Standard Information

• Model: UH952
• Brand: Century
• UPC: 7.87E+11
• Country of Origin: Mexico

Technical Specifications

• Electrical Type: Polyphase, Induction Type, Single or Dual Voltage
• HP: 2.0
• KW: 1.5
• Frame: P56H
• Diameter: 6.5 inches
• Enclosure: Drip Proof
• Phase: Three
• Voltage: 575
• Rotation: Reversible Counterclockwise
• Material: Rolled Steel
• Bearings Type: Ball / Ball
• Bearings SE Type: Ball
• Bearings OSE Type: Ball
• Mounting: Cushion Base
• Amperage: 2.4
• Shaft Type: Keyed
• Shaft Extension: 1.94 inches
• Shaft Diameter: 0.625 inches
• RPM: 3450
• Bearings DE Type: Ball
• Bearings ODE Type: Ball
• Overload: Thermally Protected
• Certification: UL Recognized, CSA Certified
