Century UH531 General Purpose Motor 1.5 HP 200-230/460V

Product Description

The Century UH531 General Purpose Motor is a versatile motor designed for various applications. This motor comes with a power output of 1.5 HP and operates at a voltage range of 200-230/460V.

• Polyphase, induction type, single or dual voltage
• 1.5 HP power output
• Rolled steel material for durability

Product Highlights

UL recognized and CSA certified, the Century UH531 motor is built for reliability and efficiency. Its drip-proof enclosure and permanently lubricated ball bearings ensure a long service life.

Product Information

Standard Information

• Brand: Century
• MPN: UH531
• Type: General Purpose Motor
• Certification: UL Recognized, CSA

Technical Specifications

• Electrical Type: Polyphase, Induction Type, Single Or Dual Voltage
• HP: 1.5
• KW: 1.1
• Frame: J56
• Diameter: 6.5
• Enclosure: Drip Proof
• Phase: Three
• Voltage: 200-230/460
• Rotation: Reversible Counterclockwise
• Overload Protection: None
• Material: Rolled Steel
• Bearings Type: Ball / Ball
• Mounting: Cushion Base
• Amperage: 4.5-4.2/2.1
• Shaft Type: Keyed
• Shaft Extension: 1.97 inches
• Shaft Diameter: 0.625 inches
• RPM: 3450
• Ambient Temperature: 40 degrees Celsius
• Frequency: 60 Hz
• Insulation Class: B
• Service Factor: 1.3
• Start Method: Across The Line
