Century UH205 General Purpose Motor 0.25 HP

Product Description

The Century UH205 General Purpose Motor with MPN UH205 is a versatile motor suitable for various applications. With a power rating of 0.25 HP, it is constructed from rolled steel and includes features that extend its durability.

• UL and CSA certification ensure safety
• Heavy-duty rolled steel enhances durability
• Permanently lubricated sealed bearings extend lifespan

Product Highlights

This motor is designed for belt-driven or fan-on-shaft applications, providing reliable performance across different uses. Its totally enclosed non-ventilated design and reversible counterclockwise rotation make it adaptable in various situations.

Product Information

Standard Information

• Brand: Century
• Model: UH205

Technical Specifications

• Electrical Type: Polyphase, Induction Type, Single Or Dual Voltage
• HP: 0.25
• RPM: 1140
• Frame: H56
• Diameter: 6.5
• Enclosure: Totally Enclosed Non Ventilated
• Phase: 3
• Voltage: 200-230/460
• Rotation: Reversible Counterclockwise
• Overload: None
• Material: Rolled Steel
• Mounting: Rigid Base
• Amperage: 1.3-1.2/.6
• Shaft Type: Keyed
• KW: 0.19
• Shaft Diameter: 0.625
• Bearings DE Type: Ball
• Bearings ODE Type: Ball
• Shaft Extension: 1.974
• Certifications CE: N
• Certifications CSA: Y
• Certifications UL: Recognized
• Insulation Class: B
