Century UH1040 General Purpose Motor 1/3 HP 200-230/460 Volts

Product Description

The Century UH1040 General Purpose Motor is designed for reliable and efficient performance in various applications. This motor features a power rating of 1/3 horsepower and operates on 200-230/460 volts. The totally enclosed air over (TEAO) design ensures durability and consistent performance.

• 1/3 HP motor
• 200-230/460 volts
• Totally enclosed air over design

Product Highlights

This motor is suitable for polyphase and induction type electrical systems. The motor's reversible counterclockwise rotation and thermally protected overload make it ideal for rigorous use in different environments.

Product Information

Standard Information

• Brand: Century
• MPN: UH1040
• Country of Origin: Mexico

Technical Specifications

• Electrical Type: Polyphase, Induction Type, Single Or Dual Voltage
• HP: 1/3
• KW: 0.25
• RPM: 1140
• Frame: L56
• Diameter: 6.5
• Enclosure: Totally Enclosed Air Over
• Phase: Three
• Voltage: 200-230/460
• Rotation: Reversible Counterclockwise
• Material: Rolled Steel
• Bearings Type: Ball / Ball
• Bearings SE Type: Ball
• Bearings OSE Type: Ball
• Mounting: Rigid Base
• Amperage: 1.9-1.8/.9
• Shaft Type: Keyed
• Shaft Extension: 1.940
• Shaft Diameter: 0.625
• Bearings DE Type: Ball
• Bearings ODE Type: Ball
• Overload Protection: Thermally Protected
• Ambient Temperature: 65°C
• Frequency: 60
• Insulation Class: B
• Poles: 6
• Service Factor: 1.5
• Starting Method: Across The Line
• Frame Prefix: L
• Frame Size: 56
• Frame Suffix: C
