Century UH047LES General Purpose Motor 1.5 HP 230/460V

Product Description

The Century UH047LES is a general purpose motor designed for a variety of applications. This motor operates on a polyphase system and provides a power output of 1.5 horsepower with a voltage range of 230/460 volts. Its frame size is 56C, making it suitable for various mounting setups.

• Rated for continuous duty with a speed of 1725 RPM.
• Constructed with rolled steel for durability.
• Features permanently lubricated sealed bearings for extended motor life.

Product Highlights

This motor is UL recognized and CSA certified for safety. The open drip-proof enclosure protects against moisture. With a threaded shaft type and an output diameter of zero point six two five inches, the UH047LES is ideal for both residential and commercial applications.

Product Information

Standard Information

• Electrical Type: Polyphase
• Enclosure Type: Open Drip Proof

Technical Specifications

• Horsepower: 1.5 HP
• Voltage: 230/460 V
• Amperage: 4.7/2.35 A
• RPM: 1725
• Frame: 56C
• Construction Material: Rolled Steel
• Bearings: Ball / Ball
• Shaft Diameter: 0.625 inches
