Century UF680 Fan and Blower Motor 3/4 HP 115/230V 1725 RPM

Product Description

The Century UF680 Fan and Blower Motor is designed for split-phase operation, delivering reliable performance with a power rating of 3/4 horsepower. This motor operates at 1725 RPM, running on a voltage of 115/230V. Its robust construction, featuring a rolled steel enclosure, ensures durability and consistent operation.

• Split-phase operation
• 3/4 horsepower power rating
• 115/230V voltage

Product Highlights

This motor from Century, MPN UF680, is ideal for HVAC applications, ensuring efficient air movement with a durable ball bearing system that prolongs its lifespan.

Product Information

Standard Information

• Brand: Century
• MPN: UF680
• Origin: Mexico
• UPC: 7.87E+11

Technical Specifications

• Electrical Type: Split Phase
• HP: 3/4
• KW: 0.56
• RPM: 1725
• Frame: 56
• Diameter: 6.5 inches
• Enclosure: ODP (Open Drip Proof)
• Phase: Single
• Voltage: 115/230
• Rotation: REV
• Material: Rolled Steel
• Bearings Type: Ball / Ball
• Bearing SE Type: Ball
• Bearing OSE Type: Ball
• Mounting: Resilient Base
• Amperage: 9.6/4.8 & 10.4/5.2
• Shaft Type: NEMA 56
• Shaft Extension: 1.880 inches
• Shaft Diameter: 0.625 inches
• Duty: Continuous
• Insulation Class: B
• Certified: CE, CSA, UL Recognized
