Century UC831 General Purpose Motor 1.5 HP 208-230/115V 1725 RPM

Product Description

The Century UC831 General Purpose Motor is built for versatile applications and optimal performance. This motor features a capacitor start and run mechanism, single or dual voltage compatibility, and a totally enclosed fan cooled enclosure. Perfect for various demanding tasks.

• Capacitor start and run for efficiency
• Rigid base mounting for stability
• Totally enclosed fan cooled enclosure for protection

Product Highlights

This motor is robust with a 1.5 HP output and can handle voltages ranging from 208-230/115V. The reversible counterclockwise rotation ensures flexibility in different setups, and ball bearings enhance longevity and smooth operation.

Product Information

Standard Information

• Brand: Century
• MPN: UC831

Technical Specifications

• Electrical Type: Capacitor Start, Capacitor Run, Single Or Dual Voltage
• HP: 1.5
• KW: 1.1
• RPM: 1725
• Frame: X56HC
• Diameter: 6.5 inches
• Enclosure: Totally Enclosed Fan Cooled
• Phase: 1
• Voltage: 208-230/115
• Rotation: Reversible Counterclockwise
• Overload Protector: None
• Material: Rolled Steel
• Bearings Type: Ball/Ball
• Mounting: Rigid Base
• Amperage: 7.8-7.5/15.0
• Shaft Type: Keyed
• Shaft Extension: 2.07 inches
• Shaft Diameter: 0.625 inches
• UL Certification: Recognized
• CSA Certification: Y
• Duty: Continuous
• Frequency: 60 Hz
• Insulation Class: B
• Poles: 4
• Service Factor: 1.15
• Ambient Temperature: 40°C
• Starting Type: Across The Line
