Century UC046 Direct Drive Motor 0.25 KW 1/3 HP

Product Description

The Century UC046 Direct Drive Motor is a versatile motor suitable for various applications. It comes with a PSC electrical type, 1/3 HP, and operates at 115/230 volts.

• [Electrical Type] PSC
• [HP] 1/3
• [KW] 0.25

Product Highlights

Ideal for HVAC applications, this motor offers reliable performance and is suitable for use in diverse environments. It features a reversible rotation and automatic overload protection.

Product Information

Standard Information

• Brand: Century
• MPN: UC046
• Type: Motor > HVAC/R Motor > Direct Drive Motor

Technical Specifications

• Electrical Type: Permanent Split Capacitor
• HP: 1/3
• KW: 0.25
• RPM: 1100
• Frame: 48Z
• Diameter: 5.6 inches
• Enclosure: Totally Enclosed Air Over
• Phase: 1
• Voltage: 115/230
• Rotation: Reversible
• Overload Protection: Automatic
• Material: Rolled Steel
• Bearings Type: Ball/Ball
• Bearings SE Type: Ball
• Bearings OSE Type: Ball
• Mounting: Resilient Base
• Amperage: 4.5/2.3
• Shaft Type: Flat
• Shaft Extension: 3.28 inches
• Shaft Diameter: 0.5 inches
• Insulation Class: B
• Frequency: 60 Hz
• Service Factor: 1
• Duty: Air Over
• Ambient Temperature: 40 degrees C
