Century UC045 Direct Drive Motor 1/4 HP 1100 RPM

Product Description

The Century UC045 Direct Drive Motor is a durable and efficient choice for HVAC systems. This motor features a Permanent Split Capacitor (PSC) and operates at 1/4 horsepower, making it suitable for various applications.

• 1/4 HP, 1100 RPM
• 115/230 volts, reversible rotation
• Totally enclosed, resilient base

Product Highlights

Reliable motor for HVAC systems, designed to offer durability, efficiency, and ease of installation.

Product Information

Standard Information

• Brand: Century
• MPN: UC045

Technical Specifications

• Electrical Type: Permanent Split Capacitor
• Horsepower: 1/4 HP
• KW: 0.19
• RPM: 1100
• Frame: 48Z
• Diameter: 5.6 inches
• Enclosure: Totally Enclosed Air Over
• Phase: 1
• Voltage: 115/230
• Rotation: Reversible
• Overload Protection: Automatic
• Material: Rolled Steel
• Bearings Type: Ball/Ball
• Shaft Type: Flat
• Shaft Extension: 3.28 inches
• Shaft Diameter: 0.5 inches
• Mounting Type: Resilient Base
• Amperage: 4.0/2.0
• Ambient Temperature: 40°C
• Insulation Class: B
• Frequency: 60
• Number of Poles: 6
• Service Factor: 1
• Capacitor Required: 6 Mfd-370 Volts (Supplied with Motor)
• Certifications: CSA, UL Recognized
