Century UB597 General Purpose Farm Duty Motor

Product Description

The Century UB597 General Purpose Farm Duty Motor is a reliable solution for various agricultural applications. This motor is designed to operate effectively in demanding environments.

• Polyphase, Induction Type, Single Or Dual Voltage
• 3/4 HP and 0.56 KW
• Totally Enclosed Non Ventilated

Product Highlights

This farm duty motor by Century, model UB597, offers durable construction and versatile performance. Thermally protected with a rigid base for secure mounting, it is suitable for high-pressure washdown applications.

Product Information

Standard Information

• Brand: Century
• MPN: UB597
• Type: General Purpose Farm Duty Motor
• Material: Rolled Steel
• Country of Origin: Mexico

Technical Specifications

• Electrical Type: Polyphase, Induction Type, Single Or Dual Voltage
• HP: 3/4
• KW: 0.56
• Frame: 56HCZ
• Diameter: 6.5 inches
• Enclosure: Totally Enclosed Non Ventilated
• Phase: Three
• Voltage: 208-230/460
• Rotation: Reversible Clockwise
• Bearings Type: Ball / Ball
• Mounting: Rigid Base
• Amperage: 2.5-2.4/1.2
• Shaft Type: Flat
• Shaft Extension: 3.23 inches
• Shaft Diameter: 0.75 inches
• RPM: 3450
• Overload: Thermally Protected
• Ambient Temperature: 40°C
• Duty: Continuous
• Frequency: 60 Hz
• Insulation Class: B
• Poles: 2
• Service Factor: 1
• Start Method: Across The Line
