Century U9724 Condenser Fan Motor 1/4 HP 208-230V 1625 RPM

Product Description

The Century U9724 Condenser Fan Motor is a reliable solution for HVAC systems. This motor offers 1/4 horsepower and operates at 1625 RPM, suitable for various HVAC applications requiring a robust and efficient motor.

• 1/4 HP
• 1625 RPM
• 208-230 Voltage

Product Highlights

The U9724 motor is designed for extended studs mounting and has a flat shaft extension. It supports single phase operations and includes an automatic overload protector.

Product Information

Standard Information

• Brand: Century
• MPN: U9724

Technical Specifications

• Electrical Type: PSC
• HP: 1/4
• KW: 0.19
• RPM: 1625
• Frame: 42
• Enclosure: TEAO
• Phase: Single
• Voltage: 208-230
• Rotation: REV
• Overload: Auto
• Material: Rolled Steel
• Bearings Type: Ball / Ball
• Mounting: Extended Studs
• Amperage: 1.7
• Shaft Type: Flat
• Shaft Extension: 3 inches
• Ambient Temperature: 60°C
• Service Factor: 1
• Insulation Class: B
• Poles: 4
• Duty: Air Over
• Start Method: Across The Line
• Shaft Diameter: 0.500 inches
