Product Description
This Century U9700 Fan and Blower Motor is a reliable choice for HVAC systems, offering a power of 1/4 HP and 1550 RPM. Its semi-enclosed design and rolled steel construction ensure durability. Ideal for single-phase systems operating at 115/208-230 volts, it features a horizontal orientation with an automatic overload protector.
- 1/4 HP motor
- 1550 RPM
- SEMI-ENCLOSED frame
Product Highlights
This motor is designed for HVAC applications, offering efficient and dependable operation. The rolled steel body ensures longevity while its CCWLE rotation and flat shaft type enhance compatibility with various systems.
Product Information
Standard Information
-
Brand: Century
-
MPN: U9700
-
UPC: 7.87E+11
-
Country of Origin: Mexico
Technical Specifications
-
Electrical Type: PSC
-
HP: 1/4
-
KW: 0.19
-
RPM: 1550
-
Frame: 48Y
-
Diameter: 5.6
-
Enclosure: SEMI-ENCLOSED
-
Phase: Single
-
Voltage: 115/208-230
-
Rotation: CCWLE
-
Overload Protector: Auto
-
Material: Rolled Steel
-
Bearings Type: Sleeve / Sleeve
-
Mounting: Resilient Ring
-
Orientation: Horizontal
-
Amperage: 4.9/2.5-2.5
-
Shaft Type: Flat
-
Shaft Extension: 4.5
-
Shaft Diameter: 0.500
-
Certifications: UL Recognized, CSA
