Century U9645 Fan and Blower Motor 1/6 HP 208-230V 48Y Frame

Product Description

The Century U9645 Fan and Blower Motor is designed for HVAC applications. This motor offers reliable performance and is built to last. With a power rating of 1/6 HP and a voltage range of 208-230V, it is suitable for various heating, ventilation, and air conditioning systems.

• 1/6 HP PSC motor
• 208-230V voltage range
• SEMI-ENCLOSED frame

Product Highlights

This motor features a flat shaft type and a shaft extension of 4.5 inches. It has a resilient ring mounting and is designed for horizontal orientation. The motor is made of rolled steel and has automatic overload protection. It operates with a single phase and has a rotation of REV.

Product Information

Standard Information

• Brand: Century
• MPN: U9645
• UPC Number: 787000000000
• Country of Origin: Mexico
• Certifications: CSA, UL Recognized

Technical Specifications

• HP: 1/6
• KW: 0.13
• RPM: 1625
• Frame: 48Y
• Diameter: 5.6 inches
• Enclosure: SEMI-ENCLOSED
• Phase: Single
• Voltage: 208-230
• Rotation: REV
• Overload: Auto
• Material: Rolled Steel
• Bearings Type: Sleeve / Sleeve
• Mounting: Resilient Rings
• Orientation: Horizontal
• Amperage: 1
• Shaft Type: Flat
• Shaft Extension: 4.5 inches
• Shaft Diameter: 0.5 inches
• Ambient Temperature: 40°C
• Service Factor: 1
• Pole: 4
• Insulation Class: B
