Century U767 Unit Heater Motor 1/4 HP 1725 RPM

Product Description

The Century U767 Unit Heater Motor is a reliable choice for various applications. This motor features a 1/4 HP power output and operates at 1725 RPM, ensuring efficient performance.

• 1/4 HP power output
• Operates at 1725 RPM
• Rolled steel construction

Product Highlights

The Century U767 Unit Heater Motor is designed for effective heating and ventilation tasks. It features ball bearings, a flat shaft, and a resilient base mounting for stable operation. The motor is made with a rolled steel material and has an automatic overload protector to enhance durability.

Product Information

Standard Information

• Brand: Century
• MPN: U767

Technical Specifications

• Electrical Type: PSC
• HP: 1/4
• KW: 0.19
• RPM: 1725
• Frame: 48Y
• Diameter: 5.6 inches
• Enclosure: TEAO
• Phase: Single
• Voltage: 115/230
• Rotation: REV
• Overload: Auto
• Material: Rolled Steel
• Bearings Type: Ball / Ball
• Bearings SE Type: Ball
• Bearings OSE Type: Ball
• Mounting: Resilient Base
• Orientation: Horizontal
• Amperage: 3.0/1.6
• Shaft Type: Flat
• Shaft Extension: 5.000 inches
• Shaft Diameter: 0.500 inches
• Certification CSA: Y
• Certification UL: Recognized
• Country of Origin: Mexico
