Product Description
Century U360 Unit Heater Motor is a reliable choice for heating applications. This motor, with 1/6 HP, operates at 115 volts and delivers 1075 RPM. Its rolled steel construction ensures durability for prolonged use.
- 1/6 HP motor for unit heaters
- Operates at 115 volts and 1075 RPM
- Constructed with rolled steel for durability
Product Highlights
The Century U360 Unit Heater Motor features a PSC electrical type. It has a single phase, with an automatic overload protector. The motor is horizontally oriented and uses sleeve bearings. It mounts using resilient rings and has a flat shaft.
Product Information
Standard Information
-
Brand: Century
-
MPN: U360
-
UPC Number: 787000000000
-
Country of Origin: Mexico
Technical Specifications
-
HP: 1/6
-
Voltage: 115
-
RPM: 1075
-
Frame: 42
-
Enclosure: TEAO
-
Phase: Single
-
Rotation: CWSE
-
Overload: Auto
-
Material: Rolled Steel
-
Bearings Type: Sleeve/Sleeve
-
Mounting: Resilient Rings
-
Orientation: Horizontal
-
Amperage: 2.6
-
Shaft Type: Flat
-
Shaft Extension: 2.96 inches
-
Shaft Diameter: 0.5 inches
-
Ambient Temperature: 40°C
-
Insulation Class: A
-
Poles: 6
-
Service Factor: 1
-
Start Method: Across The Line
-
Duty: Continuous Air Over
