CENTURY MOTORS U36 Fan and Blower Motor 1/40 HP 115 Volts

Product Description

The CENTURY MOTORS U36 is a single-phase fan and blower motor ideal for open ventilation applications. It operates at a voltage of one hundred fifteen volts and reaches three thousand RPM, providing one forty horsepower. Constructed from rolled steel, it features a three point three inch diameter and an open air over enclosure. The motor includes an automatic overload protector and sleeve bearings, ensuring reliability and safety during operation.

• Electrical Type: Shaded Pole
• Rotation: Clockwise (CWSE) and Counterclockwise (CCWLE)
• Stud mount with a bolt circle of two point eight five inches

Product Highlights

Ideal for HVAC and general ventilation systems, this motor's design enables efficient airflow and reliable performance in various conditions.

Product Information

Standard Information

• Brand: CENTURY MOTORS
• MPN: U36

Technical Specifications

• Electrical Type: Shaded Pole
• Phase: Single
• Input Voltage: 115 Volts
• Overload Protector: Automatic
• Diameter: 3.3 inches
• Enclosure: Open Air Over (OAO)
• Material: Rolled Steel
• Horsepower: 1/40 HP
• Rotation: Clockwise (CWSE) and Counterclockwise (CCWLE)
• RPM: 3000
• Current: 0.92 Amps, 60Hz
• Shaft Dimensions: 1/4 inches x 2 1/2 inches with CWSE rotation
• Mounting Type: Stud mount
• Mounting Studs: 4 at the end
• Bolt Circle: 2.85 inches
• Bearings: Sleeve bearings
• Motor Length: 3 1/8 inches
• Ventilation: Open
