Century Motors U1212A Handheld Clamp Meter

Product Description

The Century Motors U1212A is a handheld clamp meter designed for professionals measuring electrical distribution cables. It is ideal for high-current measurements without disrupting the circuit. The meter incorporates full Digital Multimeter (DMM) functions including resistance, capacitance, frequency, and temperature, making troubleshooting efficient during installation and maintenance.

• Large clamp opening of 52mm
• Rated for CAT IV 600V and CAT III 1000 V for safety
• Measures current up to 1000 A

Product Highlights

This device combines precision and safety, making it suitable for various electrical tasks.

Product Information

Standard Information

• Type: Clamp Meter
• Brand: Century Motors

Technical Specifications

• DMM Functions: AC/DC Current, AC/DC Voltage, Capacitance, Continuity, Frequency, Resistance, Temperature
• Max Current Measure AC: 1kA
• Max Voltage Measure AC: 1kV
• Max Voltage Measure DC: 1kV
• Max Resistance Measure: 4kohm
• Response Type: True RMS
• Range Selection: Auto, Manual
• Number of Digits: 4
• Jaw Opening Max: 51mm
• Product Range: U1210 Series
• Capacitance Measuring Range: 400µF to 4mF
• Current Measuring Range AC: 40A to 1kA
• Current Measuring Range DC: 40A to 1kA
• Display Count: 4100
• Temperature Measuring Range: -200°C to +1372°C
• Voltage Measuring Range AC: 400V to 1kV
• Voltage Measuring Range DC: 400V to 1kV
