CENTURY MOTORS TO108 Electric Motor 1.5 HP 3-Phase Motor

Product Description

The CENTURY MOTORS TO108 is a three-phase electric motor with a power output of 1.5 horsepower. It operates at voltages of two hundred eight to two hundred thirty or four hundred sixty volts with a frequency of sixty hertz. This motor runs at a speed of approximately three thousand four hundred fifty RPM. It features an open drip proof (ODP) enclosure and is built on a rigid base for secure mounting.

• 1.5 HP, 3-Phase Electric Motor
• Open Drip Proof (ODP) Enclosure
• Voltage Options: 208-230/460 Volts

Product Highlights

Ideal for industrial applications, this motor's robust design and features make it suitable for various tasks including driving pumps and fans.

Product Information

Standard Information

• Brand: Century
• Manufacturer Part Number: TO108

Technical Specifications

• Horsepower: 1.5
• RPM: 3482
• Input Voltage: 208-230/460
• Frequency: 60 Hz
• Phase: 3
• Frame Size: 143T
• Enclosure: ODP
• Service Factor: 1.15
• Amperage: 3.8/1.9
• Bearings: Ball Bearings
• Ambient Temperature: 40°C
• Insulation Class: F
• Rotation: Reversible
• Overload Protection: None
• Base: Rigid Base
• Shaft Diameter: 7/8 inches
• Shaft Length: 2 1/4 inches
• Agency Approvals: CE, CSA, UL
• Duty Cycle: Continuous
• Efficiency: 84.0% NEMA Nominal Efficiency
• Inverter Duty: 10:1 VT
• Dimensions: 20.00 x 18.00 x 18.00 inches
• Weight: 38 lbs
