Century SQS1202R Pool and Spa Motor 2 HP 48Y Frame

Product Description

The Century SQS1202R is a reliable pool and spa motor with a power rating of two horsepower and operates at a voltage of two hundred thirty volts. It features a permanent split capacitor design, allowing for efficient operation and energy savings. The motor is built with a square flange mounting type, making it easy to install in various applications.

• Electrical Type: Permanent Split Capacitor
• Frame: 48Y
• Amperage: 11.3/3.3

Product Highlights

This motor is designed for continuous duty, ideal for swimming pools and spas. Its open dripproof enclosure protects it from moisture, while the rolled steel construction ensures durability and longevity.

Product Information

Standard Information

• Motor Design: Permanent Split Capacitor
• Duty Cycle: Continuous

Technical Specifications

• Horsepower: 2
• Frame Size: 48Y
• Body Diameter: 5.6 inches
• Height: 5.625 inches
• Length Less Shaft: 13.625 inches
• Max Ambient Temperature: 50 degrees Celsius
• Voltage: 230V AC
• Rotation: CCWSE
• Material: Rolled Steel
• Mounting Type: Square Flange
• Weight: 34 pounds
