Century OL2034 Oil Burner Motor 1/3 HP 1725 RPM 115 Volts 48N Frame

Product Description

The Century OL2034 Oil Burner Motor is designed for domestic high and low-pressure oil burners and applications requiring 48M and 48N flange mounting. Century provides a reliable solution in HVAC and other electric motor applications, suitable for professionals seeking dependable, quiet operation. The motor adheres to NEMA standards, ensuring compatibility and performance.

• 1/3 HP, 1725 RPM, 115 volts
• Sleeve bearings, reversible rotation
• Manual reset thermal overload protector

Product Highlights

This motor features a split-phase design ideal for single-phase applications. It comes with an open shaft end bracket and can handle continuous duty cycles. The unit has reversible rotation and incorporates sleeve bearings for smooth operation.

Product Information

Standard Information

• Brand: Century
• MPN: OL2034
• Category: Electric Motors
• Manufacturer: Century, formerly A.O. Smith

Technical Specifications

• HP: 1/3
• RPM: 1725
• Voltage: 115
• Frame: 48N
• Diameter: 5.6 inches
• Enclosure: Open Drip Proof (ODP)
• Phase: Single
• Amperage: 4.3
• Rotation: Reversible
• Shaft Diameter: 0.500 inches
• Shaft Extension: 2.000 inches
• Material: Rolled Steel
• Service Factor: 1.0
• Insulation Class: B
