Century OB3204ES General Purpose Motor Three Phase 2 HP 1725 RPM

Product Description

The Century OB3204ES General Purpose Motor is designed for a variety of applications. This motor, known for its reliability, is built with high-quality components ensuring safety and efficiency.

• Three Phase, 2 HP motor
• 1725 RPM with drip-proof enclosure
• UL recognized and CSA certified

Product Highlights

The Century OB3204ES Motor is a versatile solution for numerous industrial applications, offering high efficiency and durability. Its construction using heavy-duty, rolled steel ensures longevity while permanently lubricated sealed bearings reduce maintenance.

Product Information

Standard Information

• Brand: Century
• MPN: OB3204ES
• UPC: 786674027085
• Manufacturer: Century, formerly A.O. Smith

Technical Specifications

• Electrical Type: Three Phase
• Horsepower: 2 HP
• KW: 1.5
• RPM: 1725
• Frame: 56H
• Diameter: 6.5 inches
• Enclosure: Drip Proof
• Voltage: 230/460V
• Rotation: Reversible
• Material: Rolled Steel
• Bearings Type: Ball / Ball
• Shaft Type: Keyed
• Shaft Extension: 2.23 inches
• Shaft Diameter: 0.625 inches
• Phase: Three
• UL Certification: Recognized
• CSA Certification: Yes
• Amperage: 6.0/3.0
