Century HW2014B1L 1/6 HP 115V Hot Water Circulator Motor 48Z

Product Description

The Century HW2014B1L is a hot water circulator motor designed for various industrial and residential applications. With a power rating of 1/6 HP and operating at 115 volts, this motor delivers an efficient performance at 1725 RPM. The 48Z frame ensures smooth operation and long-lasting durability.

• 1/6 HP power
• 115 volts
• 1725 RPM

Product Highlights

The Century HW2014B1L motor is ideal for hot water pumps. It features a resilient base for easy mounting and has an automatic reset thermal protector for added safety. The open drip-proof design allows for effective cooling, ensuring the motor remains operational under demanding conditions.

Product Information

Standard Information

• Brand: Century
• MPN: HW2014B1L

Technical Specifications

• Horsepower: 1/6 HP
• Voltage: 115V
• RPM: 1725
• Frame Size: 48Z
• Amperage: 3.5
• Phase: Single
• Enclosure: Open Drip Proof
• Rotation: Counterclockwise
• Shaft Diameter: 0.5 inches
• Mounting: Resilient Base
• Bearings: Sleeve
• Insulation Class: B
• Frequency: 60 Hz
• Material: Rolled Steel
• Service Factor: 1.75
• Duty: Continuous
