Century GF2038 Split Phase Resilient, 48/56 Frame, 1/3-HP, 1725-RPM, 230-Volt

Product Description

The Century GF2038 is a split phase resilient base motor designed for various applications. This motor operates at 1/3 horsepower and runs at 1725 RPM. It is suitable for 230 volts with a full load amperage of three point seven. The motor features a 48/56 frame and operates efficiently in continuous duty applications.

• Split phase design for reliable performance
• Reversible rotation options
• Includes a five eighths inch shaft adapter

Product Highlights

Engineered for HVAC systems, the GF2038 is ideal for replacing worn out motors in air conditioning and heating systems.

Product Information

Standard Information

• Brand: Century
• Type: Electric Motor

Technical Specifications

• MPN: GF2038
• Power: 1/3 HP
• RPM: 1725
• Voltage: 230 V
• Amperage: 3.7 A
• Frame Size: 48/56
• Service Factor: 1.35
• Enclosure Type: Open
• Bearings: Sleeve
• Weight: 15.43 lbs
• Dimensions: 5-5/8 inches diameter, open drip-proof design
