Century DLR1026S Blower Motor with 5.6-Inch Frame Diameter, 1/4-HP, 1075-RPM, 115-Volt, 3.6-Amp and Sleeve Bearing

Product Description

Century DLR1026S is a blower motor with a 5.6-inch frame diameter, 1/4 horsepower, and operates at 1075 RPM. This motor runs on 115 volts and draws 3.6 amps of current. Designed for continuous duty and air over applications, it is suitable for various HVAC systems.

• Energy-efficient with a permanent split capacitor design
• Durable sleeve bearings for long-lasting performance
• CCWLE rotation only

Product Highlights

This motor features resilient mounting rings for easy installation and includes an automatic overload protector for enhanced safety.

Product Information

Standard Information

• Brand: Century
• MPN: DLR1026S

Technical Specifications

• Horsepower: 0.25 hp
• Speed: 1075 RPM
• Voltage: 115 Volts
• Amperage: 3.6 Amps
• Frame Diameter: 5.6 inches
• Type: Open Enclosure
• Rotation: CCWLE
• Weight: 13.2 pounds
• Shaft Type: Flat, 0.5 inches diameter
• Mounting Type: Resilient Ring
• Insulation Class: B
• Certification: UL Recognized
