Century ARB2034L1 Fan and Blower Motor Split Phase 1/3 HP 1725 RPM 115V

Product Description

The Century ARB2034L1 Fan and Blower Motor is a versatile motor suitable for HVAC applications. This motor features split-phase electrical type and delivers 1/3 HP power. It operates at 1725 RPM with a voltage of 115V.

• Split-phase motor type
• 1/3 HP output
• Operates at 1725 RPM

Product Highlights

This motor is designed with a TEAO enclosure, ensuring durability and longevity. It supports a single-phase operation, making it ideal for various blowers and fans. The motor's automatic overload protection adds an extra layer of safety, while its resilient base ensures stable mounting.

Product Information

Standard Information

• Brand: Century
• Model: ARB2034L1
• Application: HVAC/R

Technical Specifications

• HP: 1/3
• RPM: 1725
• Voltage: 115V
• Frame: 56Z
• Phase: Single
• Amperage: 5.5/4.0
• Enclosure: TEAO
• Mounting: Resilient Base
• Shaft Type: Keyed
• Shaft Diameter: 0.625 inches
• Shaft Extension: 1.620 inches
• Material: Rolled Steel
• Bearings Type: Ball
• Overload Protection: Auto
• Duty: Continuous
• Insulation Class: B
• Ring to Ring Center: 8 7/8 inches
• Mounting Stud Pattern: 4-1/8 inches x 4-1/8 inches
• Motor Shaft Rotation: CW/CCW
