Century ARB2024L3 Belt Drive Fan and Blower Motor 1/4HP 115/208-230V 1725RPM

Product Description

The Century ARB2024L3 Belt Drive Fan and Blower Motor is a reliable 1/4 horsepower motor designed for versatile industrial applications. It features a robust rolled steel frame and compact design suitable for various voltage ranges, including 115/208-230V.

• 1/4 horsepower electric motor.
• TEAO (Totally Enclosed Air Over) enclosure.
• Single-phase, versatile voltage compatibility.

Product Highlights

This motor operates effectively at 1725 RPM and is designed with a Totally Enclosed Fan Cooled (TEAO) enclosure, ensuring protection and durability in harsh environments. Its resilient base and rolled steel construction make it ideal for HVAC applications, blowers, and fans.

Product Information

Standard Information

• Brand: Century
• Item Number: ARB2024L3
• Motor Application: HVAC/R, blowers, and fans

Technical Specifications

• Horse Power: 1/4 HP
• RPM: 1725
• Frame: 48Y
• Voltage: 115/208-230V
• Phase: Single
• Amperage: 3.3/1.7-1.7
• Enclosure: TEAO
• Mounting Type: Resilient Base
• Material: Rolled Steel
• Body Diameter: 5.6 inches
• Insulation Class: B
• Motor Thermal Protection: Auto
• Rotation: REV
• Dimensions: 16 x 16 x 12 inches
