| 9689 |
Column style=display: none;>9689 |
| Room Air Conditioner Motor |
Column style=display: none;>room air conditioner motor |
| Phase |
1 |
Column style=display: none;>phase1 |
| Frame |
42Y |
Column style=display: none;>frame42y |
| HP |
1/10 |
Column style=display: none;>hp1/10 |
| RPM |
1000 |
Column style=display: none;>rpm1000 |
| Speeds |
5 |
Column style=display: none;>speeds5 |
| Enclosure |
Open Enclosed |
Column style=display: none;>enclosureopen enclosed |
| Voltage |
208230 |
Column style=display: none;>voltage208230 |
| Rotation |
Counterclockwise Lead End |
Column style=display: none;>rotationcounterclockwise lead end |
| Bearings |
Sleeve |
Column style=display: none;>bearingssleeve |
C
Dimension |
25.50 |
Column style=display: none;>cdimension25.50 |
| Thermal Protection |
Automatic |
Column style=display: none;>thermal protectionautomatic |
| Service Factor |
1 |
Column style=display: none;>service factor1 |
|
| UPC |
786674009609 |
Column style=display: none;>upc786674009609 |
| Package Dimensions ( IN ) |
26.87 X 6.81 X 6.81 |
Column style=display: none;>package dimensions ( in )26.87 x 6.81 x 6.81 |
| Weight ( LB ) |
10.00 |
Column style=display: none;>weight ( lb )10.00 |
|
Fan Coil Dual Wheel Blower Motor
5 Diameter 42 Frame
Shaded Pole
Thermally Protected
Open Air Over
Class B Insulation 40°C Ambient
Sleeve Bearing
1/2 Diameter Double Shaft with FlatÏ´ Leads
Extened Studs Opposite Lead End Resilient Ring Mounting
