Century Motors 9649 Blower Motor 1/12 HP 115V 60 Hz Semi Enclosed Replacement 9649

Product Description

The Century Motors Model 9649 is a durable blower motor designed specifically for HVAC applications requiring reliable air circulation. Engineered with a rolled steel frame and class B insulation, this motor ensures optimal performance in various temperature conditions.

• Robust 1/12 horsepower motor supports 1050 RPM and operates on a single speed.
• Designed for horizontal installation with a lug mounting system for secure attachment.
• Features a counter-clockwise lead end rotation with sleeve bearings for prolonged operational life.

Product Highlights

This blower motor is widely used in furnace blowers, attic ventilators, air handlers, and fan coil motors.

Product Information

Standard Information

• Enclosure Type: Semi Enclosed, Open Air-Over
• Power Service Factor: 1
• Approved by: UL, CSA

Technical Specifications

• Voltage: 115 VAC 1-Phase
• Amperage: 2.9 A
• Frame Size: NEMA 42Y
• Rotation: Counter Clockwise Lead End
• Ambient Temperature Rating: 40 Degrees Celsius
