Century B813 5HP 230V ODP 3450RPM 56HZ Air Compressor Motor

Product Description

The Century B813 is a robust 5 horsepower air compressor motor designed for reliable performance in a range of industrial settings. Optimized for continuous duty, this motor operates at 3600 RPM and includes a rigid base mounting type, making it ideal for various heavy-duty applications.

• Open dripproof (ODP) enclosure type ensures protection against dust and moisture.
• Features a single-phase capacitor start and capacitor run for enhanced efficiency.
• Suitable for both horizontal mounting, this motor boasts a steel frame and a keyed shaft design.

Product Highlights

Equipped with ball bearings and a manual motor thermal protection feature, the Century B813 air compressor motor stands out with a high service factor of 1, demonstrating excellent operational resilience.

Product Information

Standard Information

• Brand: Century
• MPN: B813

Technical Specifications

• Horse Power: 5 HP
• Speed: 3600 RPM
• Voltage: 230V AC
• Amperage: 22.0
• Frame: 56HZ
• Phase: Single
• Enclosure Type: Open Dripproof
• Weight: 45 lb
• Shaft Diameter: 7/8 inches
• Shaft Length: 2 1/4 inches
