Century Motors 585 Furnace Motor 1/6 HP 115V 1050 RPM

Product Description

The Century 585 Furnace Motor is a reliable choice for maintaining your furnace's performance. This motor operates at one-sixth horsepower, delivering a consistent speed of one thousand fifty revolutions per minute at one hundred fifteen volts. The construction features a rolled steel frame and an open air over design, ensuring durability for prolonged use. With a forty-two frame size and bracket mounting, this motor serves as a versatile replacement for many furnace models.

• One-sixth horsepower ratings
• Built with durable rolled steel material
• Clockwise shaft end rotation

Product Highlights

This single-speed furnace motor operates efficiently, making it suitable for various heating applications. The design is optimized for consistent operation throughout the heating season.

Product Information

Standard Information

• Horsepower: 1/6 hp
• Voltage: 115V

Technical Specifications

• RPM: 1050 RPM
• Frame Size: 42
• Phase: 1
• Enclosure: Open air over
• Mounting: Bracket
• Rated Motor Current: 7.9 amps
• Frame Material: Rolled Steel
• Number of Speeds: 1 Speed
• Shaft Diameter: 0.5 inches
• C-Dimension: 8.25 inches
• Rotation: Clockwise shaft end
• Motor Diameter: 5 inches
• Shaft Size: 1/2 x 4 inches
• Bearings: Sleeve Bearings
• Warranty: 1 Year Manufacturer Warranty
• Weight: 10 lbs
