Century C581 3/4 HP 230/115v Belt Drive Fan Motor 1 PH 1800 RPM 56 Frame TEAO

Product Description

The Century C581 3/4 HP Belt Drive Fan Motor is a robust solution for HVAC applications. This motor operates on 230/115 volts and has a 1800 RPM speed. It fits in a 56 frame and boasts a totally enclosed air over (TEAO) enclosure type.

• 3/4 horsepower motor
• 230/115 volts operational capacity
• 1800 RPM speed

Product Highlights

This motor is ideal for HVAC systems, providing reliable performance and handling various temperature conditions up to 104°F.

Product Information

Standard Information

• Brand: Century
• MPN: C581
• Product Name: Belt Drive Fan Motor

Technical Specifications

• Horse Power: 3/4
• Voltage: 230/115V
• Rotation: RCCW
• Amperage: 3.6, 7.2/3.6, 7.2
• Frame: 56
• Phase: 1
• Speeds: 1
• Bearings: Ball
• Mount: Rigid Base
• Duty: Continuous
• Poles: 4
• Enclosure Type: TEAO
• Type: Low Starting Torque, Single or Dual Voltage, Capacitor Run, Capacitor Start
• Insulation Class: B
• Overload Protection: Thermally
• Max Ambient Temp: 104F
