Century EM3737F Pro-E Series Condenser Fan Motor 1/3 HP 460 V

Product Description

The Century EM3737F Pro-E Series Condenser Fan Motor is a 1/3 HP motor designed for HVAC applications. This single-phase motor runs on 460V and 60 Hz, with a speed of 1075 RPM and a frame size of 48. It is built to operate efficiently in air over applications, ensuring reliable performance in air conditioners and condenser units.

• Thermally protected with automatic overload protection
• Requires a 7.5 Mfd-370 Volts capacitor (not included)
• Includes extended studs for easy mounting and a half-inch diameter shaft with a double flat design

Product Highlights

This fan motor is suitable for HVAC/R applications, featuring reversible rotation, ball bearing support, and class F insulation.

Product Information

Standard Information

• Brand: Century
• MPN: EM3737F

Technical Specifications

• Phase: 1
• Output HP: 1/3 HP
• Voltage: 460 V
• Speed: 1075 RPM
• Ambient Temperature: 70 °C
• Insulation Class: F
• Current: 1.3 A
• Duty: Air Over
• Frame Size: 48Y
• Rotation: Reversible
• Drive End Bearing: Ball
• Shaft Diameter: 0.500 in
• Length: 11.80 in
• Warranty: 1 Year
• Weight: 15 pounds
