Century D541 Shaded Pole Motor 1/100 HP (3.3 in TEAO) Replacement D541

Brand: CENTURY
SKU: D541
Availability: Out Of Stock
$133.37
$133.37
HAVE A QUESTION?

Our team is ready to help!

215-326-9845
  • Voomi Supply

    Secure Payments

  • Voomi Supply

    Easy Returns

  • Voomi Supply

    Expert Advice

  • Voomi Supply

    Fast Shipping

Description

Product Description

Century D541 is a shaded pole, totally enclosed air over (TEAO) motor rated at 1/100 HP, 115 V, 60 Hz and 1550 rpm. The motor is thermally protected with Class B insulation (40 C ambient) and uses sleeve bearings with a 1/4 in shaft with flat. It features extended studs, 12 in leads with molded plug, and is designed for air over duty and OEM replacement applications.

  • Rated 1/100 HP (≈0.0075 kW), 115 V, 60 Hz, 0.60 A (reported), 1550 rpm; single phase, 1 speed
  • Totally enclosed air over (TEAO), shaded pole electrical design, thermally protected, Class B insulation
  • 3.3 in frame diameter, 0.250 in shaft with flat and 2.3 in shaft extension; sleeve bearings and extended studs

Product Highlights

Shaded pole TEAO motor, 1/100 HP, 115 V, 1550 rpm, Class B insulation, sleeve bearings, 1/4 in shaft

Product Information

Standard Information

  • Brand: CENTURY
  • Manufacturer Part Number: D541
  • Country of Origin: Mexico
Technical Specifications
Brand
Century / Fasco
MPN
D541
GTIN
818508020976
Power
1/100 HP
Power (kW)
0.0075 kW
Input Voltage
115 V
Frequency
60 Hz
Current
0.60 A (reported; plausible but flagged — may be run/start or manufacturer rating)
Phase
Single phase
Number of Speeds
1
Speed
1550 rpm
Poles
4
Rotation
Counterclockwise shaft end
Enclosure
Totally enclosed air over (TEAO)
Electrical Type
Shaded pole
Insulation Class
B
Ambient Temperature
40 C
Thermal Protection
Thermally protected
Bearings
Sleeve
Shaft Diameter
0.250 in
Shaft Type
Flat
Shaft Extension
2.3 in
Mounting
Extended studs
Frame Diameter
3.3 in
Frame Length
1.95 in
Weight
2.20 LB
Country of Origin
Mexico
UL Recognized
Yes
CSA
Y
CE
N
Service Factor
1
Starting Method
Across the line
