Century BL6519 Blower Motor 1/4-Hp (5.0-Inch)

Brand: CENTURY
SKU: BL6519
Availability: In Stock

Ships same day if ordered by 12 pm
$321.17
$321.17
HAVE A QUESTION?

Our team is ready to help!

215-326-9845
  • Voomi Supply

    Secure Payments

  • Voomi Supply

    Easy Returns

  • Voomi Supply

    Expert Advice

  • Voomi Supply

    Fast Shipping

Description

Product Description

Century BL6519 is a permanent split capacitor (PSC) blower motor rated at 1/4-Hp, 1075 RPM and 115 V. It is a single-phase, three-speed direct-drive motor with reversible rotation, sleeve bearings and automatic thermal protection, intended for HVAC, furnace blower and fan coil applications.

  • 1/4-Hp, 1075 rpm PSC motor operating at 115 V with approximately 4.7 A full load
  • Three-speed, reversible rotation with sleeve bearing construction and automatic thermal protection
  • Direct-drive 5.0-inch (42 frame) motor with 1/2-inch flatted shaft and multiple mounting options

Product Highlights

1/4-Hp, 115 V PSC blower motor; 1075 RPM; 3-speed reversible; sleeve bearings; requires 5 MFD @ 370 V capacitor

Product Information

Standard Information

  • Brand: CENTURY
  • Manufacturer Part Number: BL6519
  • Country of Origin: Mexico
Technical Specifications
Brand
Century
MPN
BL6519
Voltage
115 V
Frequency
60 Hz
Phase
Single-phase
Motor Type
Permanent split capacitor (PSC)
Horsepower
0.25 hp (1/4-Hp)
Speed (RPM)
1075 RPM
Full Load Amps
4.7 A (full load); 4.7/3.7/3.1 FLA (three speeds)
Number of Speeds
3
Rotation
Reversible (determined by viewing shaft end)
Frame Size
42 (5.0-inch diameter)
Bearing Type
Sleeve bearing
Enclosure Type
Open / Open air over (OAO)
Motor Length (less shaft)
Approx. 4-1/8 in
Mounting
3 through-bolts on 4.42 in diameter circle; supports band/ring/stud/resilient mounting
Capacitor Required
5 MFD @ 370 V (not supplied)
Thermal Protection
Automatic (auto protector)
Insulation Class
B
Service Factor
1.00
Poles
6
Duty
Air over / Continuous
Maximum Ambient Temperature
40 C
Certifications
UL and CSA
Frame Diameter
5.0 inches
Shaft Diameter
1/2 in (flatted)
Shaft Type
Flatted shaft
Typical Applications
HVAC blower, furnace blower, fan coil, direct-drive fan/blower replacement
Country of Origin
Mexico
UPC
786674014160
