Century 9723 condenser fan motor 1/4-1/5-1/6 hp 42 frame (replacement B13400252)

Brand: CENTURY
SKU: 9723
Availability: In Stock

Ships same day if ordered by 12 pm
$184.59
$184.59
HAVE A QUESTION?

Our team is ready to help!

215-326-9845
  • Voomi Supply

    Secure Payments

  • Voomi Supply

    Easy Returns

  • Voomi Supply

    Expert Advice

  • Voomi Supply

    Fast Shipping

Description

Product Description

Century 9723 is a PSC condenser fan motor rated for 208-230 VAC, single-phase operation, and multi-horsepower selection (1/6, 1/5, 1/4 hp) with a nominal speed of about 1075 RPM (range 1075-1165). The motor has reversible rotation, TEAO/TENV enclosure, ball bearings, a 7.5 µF run capacitor rating, 36-inch leads, a 1/2-inch shaft, service factor of 1, and a NEMA 42 frame for condenser and HVAC fan applications.

  • Multi-horsepower PSC motor (1/6, 1/5, 1/4 hp), single speed ~1075 RPM, 208-230 VAC, 60 Hz
  • Totally enclosed air over / non-ventilated enclosure (TEAO/TENV), ball bearings, reversible rotation
  • 0.5 in shaft diameter, 36 in lead length, extended stud mounting, 7.5 µF run capacitor rating, service factor 1

Product Highlights

Multi-horsepower 42-frame PSC condenser fan motor for 208-230 VAC HVAC condenser fan applications.

Product Information

Standard Information

  • Brand: CENTURY
  • Manufacturer Part Number: 9723
  • Country of Origin: India
Technical Specifications
Brand
Century
MPN
9723
Product Type
Condenser fan motor
Input Voltage
208-230 VAC
Frequency
60 Hz
Phase
Single
Horsepower
1/6 hp, 1/5 hp, 1/4 hp (multi-horsepower)
Speed (RPM)
1075-1165 (nominal ~1075 RPM)
Number of Speeds
1 (single)
Motor Type
PSC (Permanent Split Capacitor)
Capacitor Rating
7.5 µF run capacitor
Amps
2 A (approximate/full-load depends on hp and voltage)
Frame
NEMA 42
Enclosure Rating
Totally Enclosed Air Over (TEAO) / Totally Enclosed Non-Ventilated (TENV)
Mounting Type
Extended studs / multi-mount options
Shaft Diameter
0.5 in (1/2 in)
Shaft Length
3 in (as noted in some sources)
Lead Length
36 in
Bearing Type
Ball
Rotation
Reversible
Service Factor
1
Insulation Class
B
Duty
Continuous (S1) / Air Over
Protection
Thermal protection (reported in some sources)
Weight
12 lb
Certifications
UL recognized; CSA listed
Country of Origin
IND
