Century 9722 Condenser Fan Motor 1/8-1/10-1/12 HP (5 in) 2243

Brand: CENTURY
SKU: 9722
Availability: In Stock

Ships same day if ordered by 12 pm
$220.75
$220.75
HAVE A QUESTION?

Our team is ready to help!

215-326-9845
  • Voomi Supply

    Secure Payments

  • Voomi Supply

    Easy Returns

  • Voomi Supply

    Expert Advice

  • Voomi Supply

    Fast Shipping

Description

Product Description

Century 9722 is a multifit condenser fan motor rated 1/8-1/10-1/12 HP at 1075 RPM, designed for 208-230 VAC single-phase air-over applications. The PSC motor has a 1/2 in shaft, 36 in lead length, ball bearings, and automatic thermal protection. It supports reversible rotation and extended-stud multi-mount installation for condenser fan and HVAC replacement use.

  • Permanent split capacitor (PSC) motor; 1075 RPM, single speed; 208-230 VAC, single phase
  • Multi-horsepower 1/8-1/10-1/12 HP, 0.9 A, 42 frame with 1/2 in shaft and 36 in leads
  • Totally enclosed non-ventilated enclosure, ball bearings, reversible rotation, extended-stud multi-mount

Product Highlights

Multifit PSC condenser fan motor, 1075 RPM, 208-230 VAC, reversible, 1/2 in shaft, 36 in leads

Product Information

Standard Information

  • Brand: CENTURY
  • Manufacturer Part Number: 9722
  • Country of Origin: India
Technical Specifications
Brand
Century
MPN
9722
Voltage
208-230 VAC
Current (Amps)
0.9 A
Horsepower
1/8 HP, 1/10 HP, 1/12 HP
Speed (RPM)
1075
Number of Speeds
1 (Single)
Phase
Single
Motor Type
PSC (Permanent Split Capacitor)
Enclosure Type
Totally enclosed non-ventilated (TENV)
Duty
Continuous (S1) / Air-over
Rotation
Reversible
Bearing Type
Ball
Mounting Type
Extended studs / Multi-mounting system
Frame
42
Shaft Diameter
0.5 in (1/2 in)
Shaft Extension (Length)
3.0 in
Shaft Type
Flat
Lead Length
36 in
Service Factor
1
Insulation Class
B
Thermal Protection
Automatic
Capacitor MFD
5 µF
RPM Poles
6 poles
Ambient Temperature Rating
60 °C
Dimensions (Length x Width x Height)
8.87 in x 5.81 in x 5.81 in (packaged)
Overall Length
7.50 in
Frame Length
4.27 in
Weight
10 lb
Certifications
UL recognized; CSA listed
Country of Origin
IND
