CENTURY 6210X EVERGREEN EM Fan and Blower Motor 1 HP 115/208-230 V

Product Description

The CENTURY 6210X EVERGREEN EM is a dual voltage constant torque ECM replacement blower motor. This motor is designed for HVAC systems and offers reliable performance with its electronically commutated technology.

• Designed for 1 HP output
• Pre-programmed for immediate use
• Variable speed capability from 600-1100 RPM

Product Highlights

This blower motor features rotation sensing technology and runs at five constant torque settings, controlled via 24 VAC inputs. Its design makes it suitable for various applications in heating, ventilation, and air conditioning systems.

Product Information

Standard Information

• Brand: CENTURY
• MPN: 6210X

Technical Specifications

• Phase: 1
• Output HP: 1 Hp
• Voltage: 115/208-230 V
• Speed: 1050 rpm
• Service Factor: 1
• Frame: 48
• Enclosure: Open Air Over
• Thermal Protection: Thermally Protected
• Ambient Temperature: 40 °C
• Current: 12.2/9.0 A
• Duty: Continuous Air Over
• Insulation Class: B
• Number of Speeds: 1
• Electrical Type: Electronically Commutated Motor
• Poles: 10
• Rotation: Counterclockwise/Clockwise
• Mounting: Round
• Motor Orientation: Horizontal
• Drive End Bearing: Ball
• Opp Drive End Bearing: Ball
• Frame Material: Rolled Steel
• Shaft Type: Flat
• Overall Length: 12.45 inches
• Frame Length: 4.07 inches
• Shaft Diameter: 0.500 inches
• Shaft Extension: 4.92 inches
• Packaged Length: 15.70 inches
• Packaged Width: 6.70 inches
• Packaged Height: 7.10 inches
• Motor Design: ECM
