Centrotherm 250407503420 InnoFlue ISTCD08 Single Wall Tee Cap With Drain (8 in)

Product Description

The Centrotherm 250407503420 InnoFlue® tee cap is a single wall tee cap with drain. Designed for use with InnoFlue® polypropylene vent systems. It provides a solution for optimizing your exhaust system's performance and easily draining condensates. The integrated 30 mm drain connects to InnoFlue siphons to efficiently evacuate moisture.

• Use with any InnoFlue® siphon to drain condensate from the vent system
• Integrated 30mm drain connects with InnoFlue Siphon
• Helps to efficiently manage condensates

Product Highlights

The InnoFlue tee cap installs quickly and easily without glues, primers, or solvents. It is evaluated to UL1738 and ULCS636 by ICC.

Product Information

Standard Information

• Brand: CENTROTHERM
• Manufacturer Part Number: 250407503420
• Country of Origin: Domestic

Technical Specifications

• Cap Height: 8.9 in
• Cap Width: 8.8 in
• Domestic/Import: Domestic
• Finish: Gray
• Fits Duct Size: 8 in
• Material: Polypropylene
• Suitable For Use With: InnoFlue® Polypropylene Vent Systems
• Type: Single Wall
• Product Name: 8" Tee Cap w/Drain
• Trade name: InnoFlue
• Part number: 250407503420
• System type: Single wall
• Diameter flue pipe: 200 mm / 8 inch
• Temperature resistance (max.): 120 °C
• Certificates (US/CAN): UL 1738 – ICC-ES / ULC S636 – ICC-ES
