Centaur Rdf - 108 Series 75 Af Collet 9/32-19/64 in

Product Description

The CENTAUR RDF - 108 is a Series 75 AF collet designed for precision toolholding in machining applications. It accepts shank diameters from 9/32 inch (0.2813 inches) up to a maximum capacity of 19/64 inch (0.2969 inches), making it well suited for close-tolerance work where consistent grip and runout control matter. The collet measures 1.13 inches in overall diameter and 2.02 inches in overall length. Machinists and toolroom technicians working with Series 75 AF collet chucks will find this a direct-fit replacement or addition to existing toolholding setups.

This collet is intended for use in machine shop and production environments where Series 75 AF collet chucks are already in service. Typical applications include milling, drilling, and light turning operations on CNC and manual machine tools. It is suited for both job shop and production floor use where repeatable tool clamping within the 9/32 to 19/64 inch capacity range is required. Licensed machinists and toolroom professionals are the primary installers and end users of this component.

Key Features

• Series 75 AF collet format for direct fitment into compatible collet chucks
• Capacity range of 9/32 inch minimum to 19/64 inch (0.2969 inches) maximum
• 1.13-inch overall diameter for standard Series 75 chuck compatibility
• 2.02-inch overall length suits typical toolholding depth requirements
• Sold individually — minimum order quantity of one unit

Compatibility

Designed for use with Series 75 AF collet chucks accepting collets with a 1.13-inch outer diameter and a capacity range up to 0.2969 inches.

Installation Notes

Installation is performed by qualified machinists or toolroom technicians. Before installing or removing a collet, ensure the machine spindle is fully stopped and locked out per applicable safety procedures. Use the correct collet wrench or spanner for the Series 75 chuck to avoid damaging the collet or chuck body. Verify that the tool shank diameter falls within the 9/32 to 19/64 inch capacity range before tightening.
