Centaur Rdf - 081 Series 50 Af Collet 15/32-31/64 in

Product Description

The CENTAUR RDF - 081 is a Series 50 AF collet designed to hold workpieces or tooling within a capacity range of 15/32 to 31/64 inches (0.4844 inches maximum). It measures 0.72 inches in overall diameter and 1.16 inches in overall length. This collet is used in machine tool spindles and collet chucks that accept the Series 50 AF style. Machinists, toolroom technicians, and CNC operators install this type of collet when setting up turning, milling, or grinding operations that require precise, repeatable workholding within its rated capacity range.

This collet is suited for light to medium machining applications where consistent gripping force and accurate tool or workpiece centering are required. The Series 50 AF form factor fits corresponding collet chucks and closers designed for that series. It is appropriate for both manual and CNC machine tool setups in production shops, job shops, and toolroom environments where close-tolerance workholding is critical.

Key Features

• Collet capacity range of 15/32 to 31/64 inches for flexible workholding within that size window
• Maximum collet capacity of 0.4844 inches decimal equivalent
• Overall diameter of 0.72 inches for compatibility with Series 50 AF collet chucks
• Overall length of 1.16 inches for standard Series 50 AF spindle fit
• Series 50 AF form factor for use in matching collet chucks and closers

Compatibility

Designed for use in collet chucks and spindle noses built to accept the Series 50 AF collet standard. Verify that the host chuck or collet closer is rated for the Series 50 AF series before installation.

Installation Notes

A qualified machinist or toolroom technician should install collets in accordance with the machine tool manufacturer's procedures. Power down and lockout the machine before changing collets. Inspect the collet bore and the chuck taper for debris or damage before seating the collet. Do not exceed the rated capacity range, as doing so can damage the collet and reduce clamping accuracy.
