Cdi Torque TCQJO48ARTH Torque Wrench Head 1-1/2 in Sae

Product Description

The CDI TORQUE TCQJO48ARTH is a 1-1/2 inch open end thin torque wrench head designed for use with J-shank torque wrenches in precise fastening applications. Built for SAE measurement, this head delivers a maximum torque rating of 60 ft-lb through a 0.425 inch J-type shank interface. The thin open end profile provides access in tight clearance situations where a standard-depth head will not seat properly. At 0.45 pounds, it is lightweight enough for extended use without adding significant load to the wrench assembly. Mechanical technicians and industrial maintenance professionals rely on this type of interchangeable head to extend the versatility of a single torque wrench handle across multiple fastener sizes.

This torque wrench head is suited for professional settings where controlled torque application is required on SAE fasteners in confined spaces. The open end thin configuration makes it particularly useful on plumbing fittings, HVAC equipment mounting hardware, and mechanical assemblies where crowfoot or box-end access is limited. It is sold individually and is compatible with J-shank torque wrench handles that accept a 0.425 inch shank.

Key Features

• 1-1/2 inch open end thin head for SAE fasteners
• Maximum torque rating of 60 ft-lb
• J-type shank with 0.425 inch shank size for interchangeable torque wrench systems
• Thin profile designed for low-clearance fastening access
• Lightweight at 0.45 pounds for reduced fatigue during use

Compatibility

Designed for use with J-shank torque wrench handles that accept a 0.425 inch shank interface in SAE torque wrench systems.

Installation Notes

Installation and use of torque wrench heads should be performed by qualified mechanical or service technicians familiar with torque specifications for the fasteners being serviced. Ensure the wrench handle and head shank are fully engaged and free of debris before applying torque. Do not exceed the 60 ft-lb maximum torque rating of this head. Consult applicable equipment service manuals and relevant codes for fastener torque requirements.

Technical Specifications

• Head Size: 1-1/2 inches
• Head Type: Open End Thin
• Measurement Type: SAE
• Shank Type: J
• Shank Size: 0.425 inches
• Maximum Torque: 60 ft-lb
• Length: 3.55 inches
• Width: 2.96 inches
• Height: 0.39 inches
• Weight: 0.45 pounds
• UPC: 662459974914

Standard Information

• Brand: CDI TORQUE
• Manufacturer Part Number: TCQJO48ARTH
