Cdi Torque TCQJO40ARTH Torque Wrench Head 1-1/4 in Sae

Product Description

The CDI TORQUE TCQJO40ARTH is a 1-1/4 inch open end thin torque wrench head designed for precision fastening work where standard sockets cannot reach. This SAE head accepts a J-type shank with a 0.425 inch shank diameter, connecting directly to compatible CDI torque wrenches and drive tools. It handles a maximum torque of 60 ft-lb, making it suitable for a range of fastener sizes encountered in mechanical, HVAC, plumbing, and electrical panel work. The thin open-end profile allows access in tight or recessed spaces. At 0.32 pounds, it adds minimal weight to the tool setup. Mechanics and trade technicians working in confined equipment enclosures will find the low-profile head geometry particularly useful.

This torque wrench head is suited for residential and light commercial service work where controlled torque application on SAE fasteners is required. Typical applications include tightening refrigerant line fittings, equipment mounting hardware, panel box fasteners, and plumbing connections where a specific torque value must be met and a standard box-end or socket tool cannot be positioned. The open end thin design is especially practical on flats that are partially obstructed by flanges, brackets, or adjacent components.

Key Features

• 1-1/4 inch open end thin head for access in tight or obstructed fastener locations
• SAE measurement type for use with standard inch-unit fasteners
• J-type shank with 0.425 inch shank diameter for secure drive connection
• Maximum torque rating of 60 ft-lb
• Lightweight at 0.32 pounds, minimizing tool fatigue in overhead or confined installs
• Compact profile: 3.55 inches long, 2.56 inches wide, 0.2 inches in height

Compatibility

Designed for use with torque wrenches and drive tools that accept a J-type shank with a 0.425 inch shank diameter. Confirm shank interface compatibility with your existing torque wrench before installation.

Installation Notes

This head is installed and removed by trade technicians familiar with torque wrench systems. Ensure the shank is fully seated and secured in the torque wrench drive before applying load. Do not exceed the 60 ft-lb maximum torque rating. Verify the fastener specification calls for SAE sizing before use to avoid applying incorrect torque to metric hardware.

Technical Specifications

• Head Size: 1-1/4 inches
• Head Type: Open End Thin
• Measurement Type: SAE
• Shank Type: J
• Shank Size: 0.425 inches
• Maximum Torque: 60 ft-lb
• Length: 3.55 inches
• Width: 2.56 inches
• Height: 0.2 inches
• Weight: 0.32 pounds
• UOM: Each

Standard Information

• Brand: CDI TORQUE
• Manufacturer Part Number: TCQJO40ARTH
