Cdi Torque 50T-I Torque Wrench 15 to 75 Ft Lb

Product Description

The CDI TORQUE 50T-I is a single-setting, preset torque wrench designed for production line and repetitive fastening applications where a fixed torque value must be applied consistently. Covering a torque range of 15 to 75 foot-pounds with an overall length of 11 inches, this wrench delivers an audible click and a physical impulse when the set torque is reached. Accuracy is plus or minus 4 percent of indicated value, measured in the direction of torque application, from 20 to 100 percent of full scale. The wrench ships factory pre-set to the customer-specified torque value and includes a Certificate of Calibration.

The 50T-I is intended for use in manufacturing, assembly, and service environments where a single repeatable torque setting is required across multiple cycles. Typical applications include production line fastening in automotive, industrial, and mechanical assembly operations. The tamper-proof setting prevents unauthorized adjustment, making it well suited for quality-controlled workflows. Licensed mechanics, assembly technicians, and service professionals are the primary users of this tool.

Key Features

• Factory pre-set to customer-specified torque with Certificate of Calibration included
• Audible click and feel impulse signal at target torque value
• Accuracy: plus or minus 4 percent of indicated value from 20 to 100 percent of full scale
• Tamper-proof torque setting for production and quality-controlled environments
• Non-slip cushion grip for operator comfort during repetitive use
• Compatible with universal round shank interchangeable heads
• Meets or exceeds ASME B107.300-2010

Compatibility

Designed for use with universal round shank interchangeable heads. Specify the required torque setting at time of order placement.

Installation Notes

This wrench should be installed and used by qualified mechanical technicians familiar with torque fastening standards. Always confirm the pre-set torque value matches application requirements before use. Do not attempt to override or adjust the tamper-proof setting. Store the wrench in its protective case when not in use to maintain calibration integrity.

Technical Specifications

• Torque Range: 15 to 75 ft lb
• Overall Length: 11 inches
• Accuracy: Plus or minus 4 percent of indicated value, 20 to 100 percent of full scale
• Standard Compliance: ASME B107.300-2010
• Weight: 1.55 pounds
• Package Width: 14 inches
• Package Height: 1.8 inches
• Unit of Measure: Each
• UPC: 662459262837

Standard Information

• Brand: CDI TORQUE
• Manufacturer Part Number: 50T-I
