Cash-Acme UR22223 1in Ball Valve

Product Description

The Cash-Acme UR22223 is a 1-inch ball valve designed for water supply systems. This valve has a DZR brass body and a chrome-plated brass ball. It is suitable for a variety of plumbing needs. The maximum pressure rating is 200 psi, and it can handle temperatures up to 200 degrees Fahrenheit.

• Convenient single lever control for easy operation
• Full port design for unrestricted water flow
• Push-to-connect feature for quick and easy installation

Product Highlights

The valve features a Veradel liner, EPDM O-Ring, and PTFE packing and seat, ensuring long-lasting performance in various applications.

Product Information

Standard Information

• Brand: Cash Acme
• Application: Water Supply

Technical Specifications

• Nominal Size: 1 in
• Body Material: DZR Brass
• Ball Material: Chrome Plated Brass
• Compatible Pipe Material: Multi-Purpose
• Connectivity: Push to Connect
• Maximum Working Temperature: 200 F
• Maximum Working Pressure: 200 psi
• Product Depth: 1.662 in
• Product Height: 3 in
• Product Length: 1.662 in
• Product Width: 6.75 in
• Push to Connect: Yes
• Push-to-Fit: Yes
